当前位置：首页 » 欧美进口AG尊时凯龙人生就 » IQDAG尊时凯龙人生就 » 3215贴片晶体,LFXTAL009678,IQD石英AG尊时凯龙人生就,32.768K晶体,CFPX-217AG尊时凯龙人生就
3215贴片晶体,LFXTAL009678,IQD石英AG尊时凯龙人生就,32.768K晶体,CFPX-217AG尊时凯龙人生就
频率：32.768kHz
尺寸：3.20 x 1.50 mm
| Part Series 型号 | CFPX-217 |
| Original model 原厂编码 | LFXTAL009678 |
| Product Category 产品系列 | kHz Crystal |
| Manufacturer 品牌 | IQD Crystals |
| Frequency 频率 | 32.768kHz |
| Load capacitance 负载电容 | 12.5pF |
| frequency tolerance 频率容差 | ±20ppm |
| Package Size 包装尺寸 | 3215贴片AG尊时凯龙人生就 |
订购热线：13380314981
3215贴片晶体,LFXTAL009678,IQD石英AG尊时凯龙人生就,32.768K晶体,CFPX-217AG尊时凯龙人生就 详细参数
3215贴片晶体,LFXTAL009678,IQD石英AG尊时凯龙人生就,32.768K晶体,CFPX-217AG尊时凯龙人生就 相关产品
| Part Series 型号 | CFPX-217 |
| Original model 原厂编码 | LFXTAL009678 |
| Product Category 产品系列 | 32.768KAG尊时凯龙人生就 |
| Manufacturer 品牌 | IQD Crystals |
| Frequency 频率 | 32.768kHz |
| Load capacitance 负载电容 | 12.5pF |
| frequency tolerance 频率容差 | ±20ppm |
| Package Size 包装尺寸 | 3.20 x 1.50 mm |
| Equivalent Series Resistance 等效串联电阻 | 70 kOhms |
| Termination 脚位 | 2 Pad |
| Package Height 高度 | 0.90mm |
| Package Type 封装类型 | 3215-SMD |
| Operating Temperature 工作温度 | -40℃~85℃ |
| Packaging 包装 | Tape and Reel |
| Mounting Style 安装方式 | Surface Mount |
| 编码 | 品牌 | 系列 | Type | 频率 | 频率公差 | 负载电容 |
| LFXTAL069395RL3K | IQD Crystals | CFPX-218 | MHz Crystal | 16.384MHz | ±20ppm | 10pF |
| LFXTAL009678 | IQD Crystals | CFPX-217 | kHz Crystal | 32.768kHz | ±20ppm | 12.5pF |
| LFXTAL055299 |
IQD Crystals |
CFPX-180 | MHz Crystal | 25MHz | ±20ppm | 18pF |
| LFXTAL053099 | IQD Crystals | CFPX-180 | MHz Crystal | 27.12MHz | ±10ppm | 10pF |
| LFXTAL069383 | IQD Crystals | CFPX-218 | MHz Crystal | 24MHz | ±20ppm | 10pF |
| LFXTAL035264 | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±50ppm | 16pF |
| LFXTAL069944 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±20ppm | 15pF |
| LFXTAL035268 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±50ppm | 16pF |
| LFXTAL082071RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±10ppm | 8pF |
| LFXTAL082069RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±10ppm | 8pF |
| LFXTAL058637RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±30ppm | 12pF |
| LFXTAL063334 | IQD Crystals | CFPX-218 | MHz Crystal | 25MHz | ±20ppm | 10pF |
| LFXTAL055474 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±50ppm | 16pF |
| LFXTAL059648 | IQD Crystals | CFPX-180 | MHz Crystal | 40MHz | ±20ppm | 18pF |
| LFXTAL072604 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±10ppm | 8pF |
| LFXTAL069882 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±30ppm | 10pF |
| LFXTAL070065 | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±10ppm | 9pF |
| LFXTAL055293 | IQD Crystals | CFPX-180 | MHz Crystal | 14.7456MHz | ±50ppm | 18pF |
| LFXTAL009650 | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±10ppm | 16pF |
| LFXTAL055295 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±20ppm | 18pF |
| LFXTAL082076 | IQD Crystals | CFPX-180 | MHz Crystal | 32MHz | ±10ppm | 8pF |
| LFXTAL057997 | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±10ppm | 10pF |
| LFXTAL056346 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±30ppm | 18pF |
| LFXTAL083138RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 8MHz | ±30ppm | 12pF |
| LFXTAL058149RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±10ppm | 10pF |
| LFXTAL083409RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 26MHz | ±10ppm | 12pF |
| LFXTAL078781RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±30ppm | 12pF |
| LFXTAL083407RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±20ppm | 12pF |
| LFXTAL085880 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±20ppm | 8pF |
| LFXTAL085874 | IQD Crystals | CFPX-180 | MHz Crystal | 20MHz | ±20ppm | 12pF |
| LFXTAL085878 | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±20ppm | 12pF |
| LFXTAL085860 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±20ppm | 12pF |
| LFXTAL085887 | IQD Crystals | CFPX-180 | MHz Crystal | 32MHz | ±10ppm | 8pF |
| LFXTAL009709 | IQD Crystals | CFPX-217 | kHz Crystal | 32.768kHz | ±20ppm | 7pF |
| LFXTAL085881 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±20ppm | 12pF |
| LFXTAL085871 | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±20ppm | 8pF |
| LFXTAL009706 | IQD Crystals | CFPX-217 | kHz Crystal | 32.768kHz | ±20ppm | 9pF |
| LFXTAL054236 | IQD Crystals | CFPX-217 | kHz Crystal | 32.768kHz | ±20ppm | 6pF |
| LFXTAL069405 | IQD Crystals | CFPX-218 | MHz Crystal | 27MHz | ±20ppm | 18pF |
| LFXTAL069392 | IQD Crystals | CFPX-218 | MHz Crystal | 16MHz | ±20ppm | 10pF |
| LFXTAL059611RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 13.56MHz | ±20ppm | 18pF |
| LFXTAL054208RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±10ppm | 10pF |
| LFXTAL035265 | IQD Crystals | CFPX-180 | MHz Crystal | 20MHz | ±50ppm | 16pF |
| LFXTAL068297 | IQD Crystals | CFPX-218 | MHz Crystal | 16MHz | ±10ppm | 8pF |
| LFXTAL070868 | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±10ppm | 18pF |
| LFXTAL055951 | IQD Crystals | CFPX-180 | MHz Crystal | 16MHz | ±30ppm | 18pF |
| LFXTAL035266 | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±50ppm | 16pF |
| LFXTAL063321 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±50ppm | 18pF |
| LFXTAL059643 | IQD Crystals | CFPX-180 | MHz Crystal | 26MHz | ±20ppm | 18pF |
| LFXTAL059815 | IQD Crystals | CFPX-180 | MHz Crystal | 27.12MHz | ±50ppm | 10pF |
| LFXTAL053866 | IQD Crystals | CFPX-180 | MHz Crystal | 48MHz | ±20ppm | 18pF |
| LFXTAL058124 | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±20ppm | 18pF |
| LFXTAL051068 | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±50ppm | 9pF |
| LFXTAL055962 | IQD Crystals | CFPX-180 | MHz Crystal | 30MHz | ±10ppm | 12pF |
| LFXTAL071177 | IQD Crystals | CFPX-180 | MHz Crystal | 24MHz | ±10ppm | 9pF |
| LFXTAL083408RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 25MHz | ±20ppm | 12pF |
| LFXTAL083388RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 12MHz | ±20ppm | 12pF |
| LFXTAL083387RL3K | IQD Crystals | CFPX-180 | MHz Crystal | 10MHz | ±20ppm | 12pF |
| LFXTAL066834 | IQD Crystals | CFPX-217 | kHz Crystal | 32.768kHz | ±10ppm | 12.5pF |
